New 2025 Yamaha RAPTOR 700R SE
Vehicle Details
- Stock #: YA9069WH
- VIN: 5Y4AML6E7SA109069
- Engine: 686 cc (41.9 ci) Liquid cooled Single-Cylinder
- Exterior Color: RED-BLACK
- Transmission: Manual
Similar Vehicles
Frequently purchased together
Please select accessories from the list.
Click on the accessory link below to get more details.
Click on the accessory link below to get more details.
AFFORDABLE BIG-BORE PERFORMANCE
Based on the legendary R model, the Raptor 700 offers big‑bore performance for budget‑minded enthusiasts.
Highlighted Features
- Aggressive Style: Aggressive styling lends the Raptor 700 the menacing looks to match its impressive performance. The mighty Raptor 700 is ready to go whether the destination is the dunes, the trails or the track.
- Big-Bore Power: Powered by our most potent 686cc, liquid-cooled, fuel-injected Raptor engine ever, this big-bore Sport ATV produces big torque right off idle, transitioning into a fat mid-range and monstrous top-end.
- Advanced Suspension: The YFZ-inspired handling of the Raptor 700 is incredible to experience while blasting through the woods. Thanks to the 9.1 inches of front travel and 10.1 inches out back, the trail bumps smooth out while the rider keeps things under control. With the combination of power, solid handling and a great suspension, this machine has to be experienced to be fully appreciated.
ENGINE
- Engine Type: 686cc liquid-cooled SOHC 4-stroke; 4 valves
- Bore x Stroke: 102.0mm x 84.0mm
- Compression Ratio: 10.0:1
- Fuel Delivery: Yamaha Fuel Injection (YFI), 44mm
- Ignition: TCI: Transistor Controlled Ignition
- Transmission: 5-speed w/reverse; wet multiplate clutch
- Final Drive: X-ring chain; 2WD
- Fuel Capacity: 2.9 gal
CHASSIS
- Suspension/Front: Independent double wishbone and 5-way preload adjustment, 9.1-in travel
- Suspension/Rear: Cast aluminum swingarm with preload adjustable shock, 10.1-in travel
- Brakes/Front: Dual hydraulic disc
- Brakes/Rear: Hydraulic disc
- Tires/Front: AT22 x 7-10 Maxxis®
- Tires/Rear: AT20 x 10-9 Maxxis®
DIMENSIONS
- LxWxH: 72.6 in x 45.5 in x 43.9 in
- Seat Height: 32.7 in
- Wheelbase: 50.4 in
- Max. Ground Clearance: 9.4 in
- Fuel Capacity: 2.9 gal
- Wet Weight***: 422 lb
OTHER
- Warranty: 6 Month (Limited Factory Warranty)
